Soehnel
Except for an occasional lubrication of the transport chain the machine requires no maintenance. For repair works all function groups are easily accessible and can if required be removed from the base frame without problems.

The machine is built and designed according to the latest state of art technology and in compliance with the rules of mechanical engineering. All parts in contact with the product are made of physiologically safe material. The equipment complies with the respective safety regulations.

By utilizing different format parts, the machine is able to handle products within the following range of dimensions:

Tablet diameter Min. 13 mm Max. 28 mm
  With extra equipment 8 mm to 40 mm,
Tube diameter Min. 16 mm Max. 34 mm
  With extra equipment 10 mm to 55 mm,
Tablet stack length Max. 200 mm
Tube length Max. 220 mm
Capping diameter Max. 60 mm.

Provided that the tablets are of uniform dimensions and stable in shape, the machine can supply up to 120 filled and capped tubes per minute.
The counting accuracy is ± 0
The maximum output of the machine does not depend on the number of tablets per tube, but on the tablet material and on the tube and capping style.
